KPM Marine Force 100 Engineers Seat

Seat Type:

Helmsman / Bridge

Seat Dimensions:

Width 500mm (20")
Full Height Back

Seat Weight:

46 kg / 100 lbs

Applications:

Internal

KPM Marine Force 100 Engineers Seat is fully crash tested and type approved to HSC Code Annex 10 with DNV. This Class 3 seat offers high levels of protection and comfort where the vessel is used in demanding speed and sea state conditions. It can be used with slider or KPM type approved pedestals and accessories.

KPM Marine Force 100 Engineers Seat is a full size seat suitable for all wheelhouse seating applications at TBC 500mm (20”) width and full back. Significant weight savings are achieved by utilising a monocoque seat structure. The total weight is TBC 46kg (100lbs) for the seat and the suspension combined.

The key elements of KPM seat testing and safety are a double acting suspension system that absorbs energy in one direction when hitting waves and in the opposite direction during crash impact. The low overall seat / suspension weight reduces the dynamic force upon impact. The monocoque aluminium seat structure is designed to be compliant and absorb energy by utilising crumple zones which bend upon rear impact and absorb energy.

To optimise seat pressure distribution KPM cushions are designed to the correct firmness and pressure points are reduced by eliminating moulding contours. All seat cushions can be removed and used as flotation. KPM marine can provide the complete tested system including pedestal and floor fixings as specified by Annex 10. Features include seat tilt, weight adjustment, 4 point harness restraint, adjustable armrests and waterproof breathable fabric. Full colour options and embroidery available.

KPM Marine clients include:

UK Ministry of Defence, UK Border Force, Baltic Marine, Delta Marine, Royal Navy, RNLI (UK Lifeboat), London Port Authority, PD Tees Ports, Doeksen, South Boats, Iceni Windfarm, Seacat Services, MPI Windfarm Services, Atlas Elektronik, Blount Boats, US Marine Corps, Canadian Coastguard, Lung Teh, Strategic Marine.

Contact Details:-

KPM Marine - 85-90 Buckingham Street, Birmingham B19 3HU UK  +44 (0)1213 596434
